A68HM-E - Asus Socket FM2+ System Board (Motherboard)

SKU
A68HM-E
Brand
ASUS
Availability

In stock

$92.19

$115.24

Your Save: $23.05 25%% OFF

Product Overview

The ASUS A68HM-E is available at BulkDevices. Contact our customer service team for more information.

Manufacturer ASUS
Manufacturer Part No. A68HM-E
Condition New
Warranty 30-days

Expert Team Support

Looking for a quote for special price or bulk quantity

Easy Return

Enjoy hassle-free returns on all purchases.

Secure Payment

Shop confidently with our secure payment options.

Product Description

A68HM-E ASUS Details

A68HM-E - Asus Socket FM2+/ AMD A68H FCH/ DDR3/ SATA3/USB3.0/ A/GbE/ MicroATX Motherboard is available at Bulk Devices US.
We provide excellent customer service and we are always here when you need us.

Technical Specifications

Model
Manufacturer ASUS
Manufacturer Part # A68HME
Performance
Product Type System Board
Form Factor Micro ATX
CPU Socket Type Socket FM2+
Supported CPU(s) AMD A-Series Processor
AMD Athlon Processor
Chipset AMD A68H FCH
Number of Memory Slot(s) 2
Number of Memory Channel(s) 2
Supported Memory Standard(s) PC3-10600 (DDR3-1333)
PC3-12800 (DDR3-1600)
PC3-14900 (DDR3-1866)
PC3-19200 (DDR3-2400)
PC3-8500 (DDR3-1066)
Maximum Installed Memory 32 GB
Expansion Slots PCI
PCI-E 2.0 x1
PCI-E 2.0 x16
PCI-E 3.0 x16
Storage Controller SATA 6.0 Gbps
Audio Controller Realtek ALC887-VD
Network Gigabit Ethernet
Connectors/Ports Audio-In
Audio-Out
D-Sub
DVI
PS/2 Keyboard
PS/2 Mouse
TPM Header
USB 3.0
USB 3.1
Connectors/Ports Details Back I/O Ports
  • 1 x PS/2 keyboard (purple)
  • 1 x PS/2 mouse (green)
  • 1 x DVI
  • 1 x D-Sub
  • 1 x LAN (RJ45) port(s)
  • 2 x USB 3.1 Gen 1
  • 2 x USB 2.0
  • 3 x Audio jack(s)

  • Internal I/O Ports
  • 2 x USB 2.0 connector(s) support(s) additional 4 USB 2.0 port(s)
  • 1 x TPM connector(s)
  • 1 x COM port(s) connector(s)
  • 4 x SATA 6Gb/s connector(s)
  • 1 x CPU Fan connector(s)
  • 1 x Chassis Fan connector(s)
  • 1 x S/PDIF out header(s)
  • 1 x 24-pin EATX Power connector(s)
  • 1 x 4-pin ATX 12V Power connector(s)
  • 1 x Front panel audio connector(s) (AAFP)
  • 1 x Internal speaker connector(s)
  • 1 x System panel(s)
